SIL03-1A72-71D
RoHS
RoHS compliant
RoHS compliantPackage SIP
Category Relays / Reed Relays
Description
RELAY REED SPST 0.5A 3V
PDF
/
Buying Options
Total Price: USD $7.59
Unit Price: USD $7.586718
≥1 USD $7.586718
≥10 USD $3.02802
≥100 USD $2.926623
≥500 USD $2.876619
Inventory: 3558
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 7.8mm
Technical
Coil/Input Supply Type DC
Coil Voltage (DC) 3V
Relay Action MOMENTARY
Contact/Output Supply Type AC/DC
Contact Voltage(AC)-Max 200V
Must Release Voltage 0.45VDC
Coil Power 18mW
Contact Rating (Current) 500mA
Must Operate Voltage 2.1VDC
Contact (DC) Max Rating R Load 1A@200VDC
Release Time 0.05ms
Coil Current 6mA
Switching Voltage 200VAC 200VDC -Max
Coil Type Non Latching
Coil Voltage 3VDC
Operate Time 0.7ms
Contact (AC) Max Rating R Load 1A@200VAC
Coil Resistance 500Ohm
Relay Type Reed
Contact Form SPST-NO (1 Form A)
Throw Configuration SPST
Electrical Life 1000000000 Cycle(s)
Contact Voltage(DC)-Max 200V
Sealing WATER PROOF
Contact Resistance 100mOhm
Physical Dimension 19.8mm x 5.08mm x 7.8mm
Body Breadth 5.08 mm
Body Length or Diameter 19.8mm
Termination Style PC Pin
Reference Standard UL
Reach Compliance Code unknown
Packing Method BULK
Terminal Finish TIN
ECCN Code EAR99
Termination PC Pin
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Diode
JESD-609 Code e3
Series SIL
Published 2012
Packaging Tube
Operating Temperature -20°C~70°C
Physical
Weight 1.6g
Package / Case SIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
