H12-1B83
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / Reed Relays
Description
STANDEXMEDER H12-1B83 REED RELAY, HIGH-VOLTAGE 12vDC
PDF
/
Inventory: 2087
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 29.1mm
Height 30mm
Technical
Coil Current(DC)-Max 0.067A
Switching Current 3A
Coil/Input Supply Type DC
Coil Voltage (DC) 12V
Relay Action MOMENTARY
Contact/Output Supply Type AC/DC
Contact Voltage(AC)-Max 7500V
Coil Power 800mW
Contact (DC) Max Rating R Load 3A@7500VDC
Release Time 1.5 ms
Switching Voltage 7.5kV
Operate Time 3 ms
Contact (AC) Max Rating R Load 3A@7500VAC
Coil Resistance 180Ohm
Contact Current(AC)-Max 3A
Relay Type DRY REED RELAY
Throw Configuration SPST
Number of Poles 1
Electrical Life 50000000 Cycle(s)
Termination Type SOLDER
Contact Voltage(DC)-Max 7500V
Sealing WATER PROOF
Contact Current(DC)-Max 3A
Contact Resistance 150mOhm
Packing Method BULK
HTS Code 8536.49.00.50
Min Operating Temperature -20°C
Max Operating Temperature 70°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2002
Physical
Number of Pins 2
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
