ASSR-3220-002E

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 8-DIP (0.300, 7.62mm)
Category Relays / Solid State Relays
Description SSR RELAY SPST-NO 200MA 0-250V
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.7974
≥1 USD $1.7974
≥10 USD $1.47535
≥100 USD $1.4288
≥500 USD $1.3832
≥1000 USD $1.33665
Inventory: 1525
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Length 9.65mm
Height 3.56mm

Technical

Control Current 0.003A
Isolation Voltage 3.75kV
On-State Current-Max 0.2A
Input Current 20mA
Max Input Current 20mA
On-State Resistance (Max) 10Ohm
RMS Current (Irms) 200mA
Voltage - Load 0V~250V
Relay Type Relay
Max Input Voltage 1.65V
Max Output Voltage 250V
Forward Current 20mA
Optoelectronic Device Type TRANSISTOR OUTPUT SSR
Input Type DC
Throw Configuration DPST
Output Current 200mA
Voltage - Input 1.3VDC
Circuit SPST-NO (1 Form A) x 2
Number of Elements 2
Max Output Current 200mA
Output Type AC, DC
Output Voltage 250V
Termination Style PC Pin
Depth 6.35mm
Voltage - Rated DC 250V
Additional Feature UL RECOGNIZED, CMOS COMPATIBLE
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 10Ohm
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series ASSR
Published 2007
Packaging Tube

Physical

Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount PCB, Through Hole
Contact Plating Tin

Supply Chain

Factory Lead Time 17 Weeks
