813-22-072-30-002101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
CONN SPRING CONT 72 POS .197 SMD
PDF
/
Buying Options
Total Price: USD $28.17
Unit Price: USD $28.1688
≥1 USD $28.1688
≥10 USD $24.66904
≥100 USD $23.603008
≥500 USD $22.841632
≥1000 USD $22.080344
≥3000 USD $20.86209
Inventory: 127
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 20.0μin 0.51μm
Length 91.44mm
Technical
Contact Pattern RECTANGULAR
Durability 1000000 Cycles
Dielectric Withstanding Voltage 1000VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 100V
Row Spacing 0.100 (2.54mm)
Insulation Resistance 10000000000Ohm
Contact Resistance 20mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 2A
Housing Color Black
UL Flammability Code 94V-0
Mating Information NO
PCB Contact Pattern RECTANGULAR
Number of Contacts 72
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Current Rating 3A
Depth 5.08mm
Orientation Straight
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.90.40.00
Additional Feature LOW PROFILE
Gender Male
Number of Rows 2
Connector Type Piston
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 813
Published 2005
Packaging Tube
Physical
Housing Material Nylon
Material Copper Alloy
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Brass
Supply Chain
Factory Lead Time 3 Weeks
