M90-7011645

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description CONN SPRING TARGET 16POS FLANGE
PDF
/
Inventory: 4294
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 18mm
Length 47mm

Technical

Insulator Color BLACK
Contact Pattern RECTANGULAR
Max Current Rating 1A
Body/Shell Style RECEPTACLE
Row Spacing 0.098 (2.50mm)
Insulation Resistance 1GOhm
Contact Resistance 30mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 1A
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender Male
Body Breadth 0.708 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 16
Lead Pitch 2.5mm
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Current Rating 1A
Depth 18mm
Orientation Straight
Pitch 0.098 2.50mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.30
Additional Feature ROHS COMPLIANT
Voltage - Rated 240V
Number of Rows 2
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Connector Type Mating Target
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series HotShoe
Published 2009
Packaging Bulk

Physical

Housing Material Polyamide
Material Brass
Mounting Type Panel Mount, Flange; Through Hole
Mount Flanges, Panel, Through Hole

Supply Chain

Factory Lead Time 5 Weeks
