776524-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG ASSY 4POS 18-20AWG RED
PDF
/
Buying Options
Total Price: USD $2.09
Unit Price: USD $2.0944
≥1 USD $2.0944
≥10 USD $1.902402
≥100 USD $1.760202
≥500 USD $1.676321
≥1000 USD $1.475602
Inventory: 1257
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Material Thermoplastic
Housing Material Polybutylene
Body Material PBT
Technical
Packaging Bulk
Published 2008
Series AMPSEAL 16
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Plug
Number of Positions 4
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Color Black
Number of Rows 2
Gender Male
Fastening Type Latch Lock
Contact Type Female Socket
Pitch 0.177 4.50mm
Orientation Straight
Depth 39.95mm
Number of Contacts 4
Housing Color Red
Row Spacing 0.209 (5.30mm)
Note Contacts Not Included
Contact Termination Crimp
Hybrid Connector No
Polarized Yes
Serviceable Yes
Dimensions
Height 26.797mm
Length 25.33mm
Width 36.703mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 HB
Lead Free Lead Free
