776437-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG ASSY 12PS 14-18AWG RED
PDF
/
Buying Options
Total Price: USD $4.49
Unit Price: USD $4.488
≥1 USD $4.488
≥10 USD $4.073142
≥100 USD $3.588438
≥500 USD $2.601623
Inventory: 493
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 36.8mm
Length 38.33mm
Height 31.496mm
Technical
Polarized Yes
Hybrid Connector No
Contact Termination Crimp
Note Contacts Not Included
Row Spacing 0.209 (5.30mm)
Empty Shell NO
Housing Color Red
Orientation Straight
Total Number of Contacts 12
Pitch 0.177 4.50mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Latch Lock
HTS Code 8536.69.40.30
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Number of Positions 12
Connector Type Plug
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPSEAL 16
Published 2008
Packaging Bulk
Physical
Body Material PBT
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 2 Weeks
