770075-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RECEPT W/DETENT 4POS .093
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.33352
≥100 USD $0.277728
≥500 USD $0.206923
≥1000 USD $0.184703
≥3000 USD $0.171873
Inventory: 3233
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 6.1mm
Length 28.58mm
Height 22.1mm
Technical
Contact Retention Without
Contact Termination Crimp
Sealable No
Max Voltage Rating (AC) 250V
ELV Compliant
Note Contacts Not Included
Operating Supply Voltage 250V
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 4
Approval Agency CSA
Current Rating 13A
Depth 28.58mm
Orientation Straight
Pitch 0.198 5.03mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male or Female
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN/GOLD (30) OVER NICKEL
Fastening Type Locking Ramp
Voltage - Rated 250V
Number of Rows 1
Color Natural
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Commercial .093 Pin and Socket
Published 2006
Packaging Bulk
Physical
Housing Material Nylon
Shell Material POLYAMIDE
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 4 Weeks
