39-00-0039

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description MOLEX 39-00-0039Contact, Mini-Fit Jr., 5556 Series, Socket, 24 AWG, 18 AWG, Crimp, Brass
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.08645
≥1 USD $0.08645
≥10 USD $0.07125
≥100 USD $0.06935
≥500 USD $0.0665
≥1000 USD $0.0646
≥10000 USD $0.05795
Inventory: 1567
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Brass
Contact Plating Tin
Mount Cable, Through Hole
Housing Material Polyamide

Technical

Packaging Bulk
Published 2009
Pbfree Code yes
Termination Crimp
ECCN Code EAR99
Connector Type Connector, Crimp, PCB, Power, Signal, Socket
Resistance 10mOhm
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Number of Rows 2
Voltage - Rated 600V
HTS Code 8536.90.40.00
Pitch 4.2mm
Orientation Straight
Shielding Unshielded
Depth 3.6mm
Current Rating 9A
Voltage - Rated AC 250V
Number of Contacts 1
Contact Gender Female
Housing Color Natural
Contact Resistance 20mOhm
Max Voltage Rating (AC) 250V
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 24 AWG
Wire/Cable Gauge 24 AWG
Terminal and Terminal Block Type PUSH-ON TERMINAL
Wire/Cable Diameter 3.1 mm
Current Rating (Max) 9A

Dimensions

Height 4.5mm
Length 14.7mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
