2822390-1 image
Favorite
2822390-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Rectangular Connector Housing
PDF
/
Buying Options
Total Price: USD $1.53
Unit Price: USD $1.5312
≥1 USD $1.5312
≥10 USD $1.39744
≥100 USD $1.355552
≥500 USD $1.342
≥1000 USD $1.24564
≥3000 USD $1.22496
Inventory: 3118
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 22.7838mm
Length 25.4mm
Height 27.5844mm

Technical

Polarized Yes
Hybrid Connector No
Mating Tab Width 1.8mm
Contact Termination Crimp
Circuit Application Signal
Note Contacts Not Included
Number of Contacts 3
Depth 27.6mm
Orientation Straight
Pitch 0.189 4.80mm
Contact Type Female Socket
Fastening Type Latch Holder
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 3
Connector Type Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Sealed
Series EconoSeal J Mark II
Published 2005
Packaging Bulk

Physical

Body Material PBT
Housing Material PBT
Mounting Type Free Hanging (In-Line)

Supply Chain

Factory Lead Time 24 Weeks
