2822344-1 image
Favorite
2822344-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description TE Connectivity Mini Multilock Series 2.4mm Pitch 7 Way 3 Row Female Straight PCB Housing
PDF
/
Buying Options
Total Price: USD $3.04
Unit Price: USD $3.0419
≥1 USD $3.0419
≥10 USD $2.49565
≥100 USD $2.41775
≥500 USD $2.33985
≥1000 USD $2.26195
Inventory: 1156
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 20 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)

Physical

Mounting Type Free Hanging (In-Line)
Housing Material PBT
Body Material PBT

Technical

Packaging Bulk
Published 2011
Series Mini Multilock
Feature Sealed
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 7
Max Operating Temperature 221°C
Min Operating Temperature -40°C
Color Green
Number of Rows 3
Gender Receptacle
Fastening Type Locking Ramp
Contact Type Tab
Pitch 0.094 2.40mm
Orientation Straight
Depth 24.9mm
Number of Contacts 7
Row Spacing 0.079 (2.00mm)
Note Contacts Not Included
Circuit Application Signal
Contact Termination Crimp
Mating Tab Width 787.4μm
Hybrid Connector No
Polarized Yes
Serviceable No

Dimensions

Height 24.9mm
Length 11mm
Width 11.6078mm

Compliance

REACH SVHC No SVHC
RoHS Status RoHS Compliant
