1-1903128-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings DYNAMIC 1100D TAB HSG 22P P/M
PDF
/
Buying Options
Total Price: USD $2.87
Unit Price: USD $2.8688
≥1 USD $2.8688
≥10 USD $2.552
≥100 USD $2.539328
≥500 USD $2.513104
≥1000 USD $2.265736
≥3000 USD $2.25273
Inventory: 385
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Panel Thickness 1.9812mm
Width 13.9mm
Length 30.7594mm
Height 20.9804mm
Technical
VDE Tested No
Preloaded No
Halogen Free Halogen Free
Contact Termination Crimp
Circuit Application Signal
Sealable No
Wire/Cable Gauge 22 AWG
Max Voltage Rating (AC) 125V
ELV Compliant
Note Contacts Not Included
Row Spacing 0.130 (3.30mm)
Operating Supply Voltage 125V
Housing Color Black
Number of Contacts 22
Approval Agency UL
Depth 21mm
Orientation Straight
Pitch 0.079 2.00mm
Contact Type Tab
Voltage - Rated 125V
Number of Rows 2
Color Black
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 22
Connector Type Plug
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Dynamic D-1100
Published 2007
Packaging Bulk
Physical
Housing Material Polyester
Mounting Type Panel Mount, Snap-In
Mount Panel
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 18 Weeks
