1-172142-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings REC HSG LP EI CONN
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.805548
≥1 USD $0.805548
≥10 USD $0.759951
≥100 USD $0.716936
≥500 USD $0.676353
≥1000 USD $0.63807
Inventory: 938
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Length 32mm
Height 6.7mm
Technical
Mating Retention With
Contact Termination Crimp
Contact Current Rating 2A
Sealable No
Dielectric Withstanding Voltage 750VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Note Contacts Not Included
Insulation Resistance 500MOhm
Rated Current (Signal) 2A
Operating Supply Voltage 250V
UL Flammability Code 94V-0
Body Breadth 0.283 inch
Approval Agency UL
Reliability COMMERCIAL
Current Rating 2A
Depth 8mm
Orientation Straight
Total Number of Contacts 12
Pitch 0.098 2.50mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 1
Color Natural
Number of Positions 12
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series EI
Published 1999
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 15 Weeks
