794594-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Pin & Socket Connectors 02 DUAC PLUG HSG 94V-0 FR/HANG
PDF
/
Inventory: 945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mount Cable, Free Hanging
Shell Material POLYAMIDE
Housing Material Nylon
Technical
Packaging Bulk
Pbfree Code yes
Termination Crimp
ECCN Code EAR99
Connector Type Pin, Plug
Number of Positions 2
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color White
Number of Rows 2
Gender Male
Additional Feature AMP-DUAC
HTS Code 8536.69.40.30
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 4.2mm
Total Number of Contacts 12
Orientation Straight
Depth 23.9mm
Current Rating 9A
Reference Standard UL
Reliability COMMERCIAL
Row Spacing - Mating 4.191 mm
Body Breadth 0.46 inch
UL Flammability Code 94V-0
Empty Shell NO
VDE Tested Yes
Contact Pattern RECTANGULAR
Wire/Cable Gauge 26 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 26 AWG
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 600V
ELV Compliant
Insulation Resistance 1000000000Ohm
Contact Resistance 5mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 9A
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 23.9mm
Length 5.4mm
Height 11.7mm
