1-1419158-8
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
HARNESS HSG(GEM)23P
PDF
/
Buying Options
Total Price: USD $2.66
Unit Price: USD $2.660828
≥1 USD $2.660828
≥10 USD $2.510215
≥100 USD $2.368128
≥500 USD $2.234077
≥1000 USD $2.107628
Inventory: 1116
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 24.6888mm
Length 29.9974mm
Height 23.0378mm
Technical
Polarized No
Hybrid Connector Yes
Mating Tab Width 2.794mm
Circuit Application Signal
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Empty Shell YES
Contact Gender FEMALE
Orientation Straight
Total Number of Contacts 23
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
HTS Code 8536.69.40.30
Number of Rows 2
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 212°C
Number of Positions 23
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Packaging Bulk
Physical
Housing Material Polyamide
Mount Cable, Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
