03-09-1091
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RECEPT 9POS .093 PANEL MNT
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.01201
≥1 USD $1.01201
≥10 USD $0.954723
≥100 USD $0.900682
≥500 USD $0.8497
≥1000 USD $0.801612
Inventory: 6236
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 25.8mm
Length 16.9mm
Height 18.59mm
Technical
Glow Wire Compliant Non-compliant
Number of Lines 3
Contact Pattern RECTANGULAR
Polarization Key POLARIZED HOUSING
Operating Supply Voltage 250V
Empty Shell YES
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Lead Pitch 5.03mm
Row Spacing - Mating 5.0292 mm
Approval Agency CSA, UL
Reliability COMMERCIAL
Voltage - Rated AC 250V
Reference Standard UL, CSA
Current Rating 14A
Depth 25.4mm
Orientation Straight
Total Number of Contacts 9
Pitch 5.03mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Gender Receptacle
Number of Rows 1
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 9
Connector Type Male or Female, Receptacle, Socket
Termination Crimp
Pbfree Code yes
Published 2000
Packaging Bulk
Physical
Housing Material Nylon
Mount Panel, Snap in
Supply Chain
Factory Lead Time 8 Weeks
