KPSE06B16-8S

ITT Cannon, LLC
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description ITT CANNON KPSE06B16-8S Circular Connector, KPSE Series, MIL-DTL-26482 Series I Equivalent, Straight Plug, 8, Crimp Socket
PDF
/
Inventory: 8596
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Copper
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Aluminum Alloy
Body Material Aluminium

Technical

Operating Temperature -55°C~125°C
Packaging Bulk
Published 2016
Series KPSE
Feature Strain Relief
Part Status Active
Termination Crimp
ECCN Code EAR99
Connector Type Plug, Female Sockets
Number of Positions 8
Color Olive Drab
Gender Male
Voltage - Rated 1000VAC 1400VDC
Fastening Type Bayonet Lock
Contact Finish - Mating Gold
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option WATER PROOF
Total Number of Contacts 8
Orientation N (Normal)
Current Rating 13A
Shell Finish Olive Drab Cadmium
Shell Size - Insert 16-8
Empty Shell YES
Backshell Type SOLID
Max Current Rating 22A
Plating Cadmium, Chromate
Body Plating Cadmium

Dimensions

Length 49mm
Contact Finish Thickness - Mating 50.0μin 1.27μm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
