DF7-4EP-3.96C
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG HOUSING 4POS 3.96MM CR
PDF
/
Inventory: 8772
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Contact Plating Brass
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Shell Material POLYAMIDE
Housing Material Nylon
Technical
Packaging Bulk
Series DF7
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Plug
Number of Positions 4
Color White
Number of Rows 1
Gender Female
Fastening Type Latch Holder
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.156 3.96mm
Total Number of Contacts 4
Reach Compliance Code unknown
Reference Standard UL,CSA,TUV
Reliability COMMERCIAL
Body Length or Diameter 0.997 inch
Lead Pitch 3.96mm
Operating Temperature (Max) 85°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.39 inch
Operating Temperature (Min) -35°C
Empty Shell NO
Contact Resistance 5mOhm
Note Contacts Not Included
Polarization Key POLARIZED HOUSING
Durability 30 Cycles
Withdrawl Force-Min .3058 N
Contact Termination Crimp
Wire Size (Min) 22 AWG
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
