5536255-9 image
Favorite
5536255-9 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description Board to Board & Mezzanine Connectors 200,VT,RC,BD, BD,30AU,180ST
PDF
/
Inventory: 8667
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Stack Height 18.7452mm
Length - Tail 4.4958mm
Length - Termination 0.18 inch
Plating Thickness 30μin
Height 8.11mm

Technical

Stackable No
Preloaded Yes
Contact Rating (Current) 10.5A
Contact Pattern RECTANGULAR
Durability 50 Cycles
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Insulation Resistance 5000000000Ohm
Contact Style SQ PIN-SKT
Contact Gender FEMALE
PCB Contact Pattern STAGGERED
Number Of PCB Rows 5
Row Spacing - Mating 2.54 mm
Body Length or Diameter 5.14 inch
Reliability COMMERCIAL
Number of Conductors ONE
Orientation Straight
Total Number of Contacts 200
Pitch 1.2446mm
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Color Natural
Min Operating Temperature -85°C
Max Operating Temperature 257°C
Number of Positions 200
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Solder

Physical

PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Gold, Tin
Contact Material Bronze
