22-28-4026
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
HEADER, 2WAY
PDF
/
Buying Options
Total Price: USD $0.71
Unit Price: USD $0.709254
≥1 USD $0.709254
≥10 USD $0.669109
≥100 USD $0.631231
≥500 USD $0.595496
≥1000 USD $0.561787
Inventory: 5444
Minimum: 1
-
+
Technical Details
Technical
Number Of PCB Rows 1
Contact Length - Mating 6.096mm
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.098 inch
UL Flammability Code 94V-0
Body Depth 0.09 inch
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Body/Shell Style RECEPTACLE
Max Voltage Rating (DC) 250.25kV
Contact Pattern RECTANGULAR
Withdrawl Force-Min .556 N
Glow Wire Compliant Non-compliant
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 4A
Orientation Vertical
Total Number of Contacts 2
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature SURFACE-MOUNT COMPATIBLE
Voltage - Rated 250V
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Number of Positions 2
Connector Type Male Pin
ECCN Code EAR99
Termination Through Hole
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Gold
Contact Material Brass
