5147734-3
RoHS
/
Package Module
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings 08 MODII HORZ DR SFMNT 10AU
PDF
/
Inventory: 9894
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 10.16mm
Technical
High Temperature Compatible Yes
ELV Compliant
Contact Resistance 12mOhm
UL Flammability Code 94V-0
Contact Gender FEMALE
Number of Contacts 8
Row Spacing - Mating 2.54 mm
Approval Agency CSA, UL
Current Rating 2A
Depth 8.13mm
Orientation Right Angle
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature -125°C
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination SMD/SMT
Pbfree Code yes
Packaging Bulk
Physical
PCB Mounting Orientation Right Angle
Housing Material Polyester
Package / Case Module
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
