SSM-104-S-DV-BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 8 POS 2.54mm Solder ST SMD Tube
PDF
/
Buying Options
Total Price: USD $3.34
Unit Price: USD $3.34177
≥1 USD $3.34177
≥10 USD $3.152615
≥100 USD $2.97416
≥500 USD $2.805814
≥1000 USD $2.646996
Inventory: 953
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Length 10.16mm
Technical
Max Current Rating 6.9A
Max Voltage Rating (AC) 475V
Contact Resistance 10mOhm
Contact Finish - Post Tin
Row Spacing - Mating 0.100 (2.54mm)
Insulation Color Black
Pitch - Mating 0.100 2.54mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.290 7.37mm
Depth 5.08mm
Orientation Straight
Total Number of Contacts 8
Current Rating (Amps) 5.2A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Additional Feature E.L.P., TIGER CLAW
Voltage - Rated 405VAC 572VDC
Gender Female
Number of Rows 2
Number of Positions 8
Connector Type Receptacle, Bottom Entry
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SSM
Published 2014
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Housing Material Polymer
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
