SQT-120-01-H-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip SKT 40 POS 2mm Solder ST Thru-Hole Tube
PDF
/
Inventory: 5366
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Body Breadth 0.157 inch
Body Depth 0.079 inch
Contact Resistance 10mOhm
Mating Contact Pitch 0.079 inch
Polarization Key POLARIZED HOUSING
Withdrawl Force-Min .834 N
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Contact Length - Post 0.090 2.29mm
Row Spacing - Mating 0.079 (2.00mm)
Body Length or Diameter 1.586 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.250 6.35mm
Current Rating (Amps) 5.1A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Forked
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Voltage - Rated 450VAC
Gender Female
Number of Rows 2
Number of Positions 40
Connector Type Receptacle
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series SQT
Packaging Bulk
Operating Temperature -55°C~125°C
Dimensions
Plating Thickness 50μin
Contact Finish Thickness - Mating 50.0μin 1.27μm
Contact Finish Thickness - Post 3.00μin 0.076μm
Length - Termination 0.09 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Physical
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 3 Weeks
