SFM-140-01-S-D-LC-K
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Tiger Eye? SFM ROHS3Compliant COMMERCIAL RECTANGULAR Connector Receptacle -55C~125C 3.2A per Contact 250VAC 0.145inch
PDF
/
Inventory: 9326
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.180 4.57mm
Current Rating (Amps) 3.2A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Additional Feature TIGER EYE CONTACT
Voltage - Rated 250VAC
Gender Female
Number of Rows 2
Number of Positions 80
Connector Type Receptacle
Termination Solder
Part Status Active
Feature Board Lock, Pick and Place
JESD-609 Code e3
Series Tiger Eye? SFM
Packaging Bulk
Operating Temperature -55°C~125°C
Mating Contact Pitch 0.05 inch
Body Depth 0.18 inch
Body Breadth 0.145 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 2
Contact Length - Post 0.120 3.05mm
Row Spacing - Mating 0.050 (1.27mm)
Reliability COMMERCIAL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Physical
Board Mounting Option SPLIT BOARD LOCK
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 3 Weeks
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Stack Height (Mating) 6.02mm 6.17mm 7.80mm 7.95mm 9.58mm 9.73mm 11.48mm 11.63mm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Plating Thickness 30μin
