S2M-125-01-L-D

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description SAMTEC - S2M-125-01-L-D - CONNECTOR, RECEPTACLE, 2MM, 50WAY
PDF
/
Buying Options
Total Price: USD $10.87
Unit Price: USD $10.868
≥1 USD $10.868
≥10 USD $10.0408
≥100 USD $9.4952
≥500 USD $9.152
≥1000 USD $7.0488
≥3000 USD $6.611
Inventory: 254
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Plating Thickness 10μin

Technical

Insulator Color BLACK
Mating Contact Row Spacing 0.079 inch
Withdrawl Force-Min .417 N
Insertion Force-Max .556 N
Contact Pattern RECTANGULAR
Body/Shell Style SOCKET
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
Body Depth 0.178 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number of Contacts 50
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Orientation Vertical
Pitch 2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature TIGER EYE CONTACT
Gender Receptacle
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2011

Physical

Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Mount Through Hole
Contact Plating Gold
Contact Material Copper

Supply Chain

Factory Lead Time 3 Weeks
