ESQT-142-03-L-Q-375
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
CONN SOCKET 168P 0.079 GOLD PCB
PDF
/
Inventory: 1897
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Contact Shape Square
Insulation Material Liquid Crystal Polymer (LCP)
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series ESQT
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Connector Type Elevated Socket
Number of Positions 168
Number of Rows 4
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
Contact Type Forked
Current Rating (Amps) 4.5A per Contact
Terminal Pitch 2.0066mm
Insulation Height 0.375 9.53mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL
PCB Contact Row Spacing 2.0066 mm
Dielectric Withstanding Voltage 600VAC V
Mating Contact Pitch 0.079 inch
Insulation Resistance 5000000000Ohm
Body Depth 0.25 inch
Contact Gender FEMALE
Body Breadth 0.158 inch
PCB Contact Pattern RECTANGULAR
Contact Finish - Post Tin
Number Of PCB Rows 4
Contact Length - Post 0.083 2.11mm
Row Spacing - Mating 0.079 (2.00mm)
Body Length or Diameter 1.659 inch
Reliability COMMERCIAL
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length - Termination 0.375 inch
Contact Finish Thickness - Mating 10.0μin 0.25μm
Plating Thickness 10μin
