CLH-133-L-D-DV-LC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Rectangular Connector Header
PDF
/
Inventory: 7037
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Plating Thickness 10μin
Technical
Insulator Color BLACK
Mating Contact Row Spacing 0.1 inch
Contact Pattern RECTANGULAR
Durability 100 Cycles
Body/Shell Style SOCKET
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 1.5A
Operating Temperature (Min) -65°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number of Contacts 66
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Gender Female
Number of Rows 2
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Physical
Board Mounting Option SPLIT BOARD LOCK
Mounting Style STRAIGHT
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Mounting Type BOARD
Contact Plating Gold
Contact Material PHOSPHOR BRONZE
