CLH-131-L-D-PE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
SAMTEC CLH-131-L-D-PE Board-To-Board Connector, Vertical, 62 Contacts, Receptacle, 2.54 mm, Through Hole, 2 Rows
PDF
/
Inventory: 7338
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Through Hole
Insulation Material LIQUID CRYSTAL POLYMER (LCP)
Technical
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type BOARD CONNECTOR
Number of Rows 2
Gender Receptacle
Additional Feature LOW PROFILE
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 3.1 inch
Number Of PCB Rows 2
Number of Contacts 62
PCB Contact Pattern RECTANGULAR
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Min) -65°C
Body Depth 0.14 inch
Rated Current (Signal) 1.5A
Contact Style SQ PIN-SKT
Contact Resistance 10mOhm
Body/Shell Style SOCKET
Durability 100 Cycles
Contact Pattern RECTANGULAR
Mating Contact Row Spacing 0.1 inch
Insulator Color BLACK
Dimensions
Plating Thickness 10μin
Length - Termination 0.09 inch
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
