0791098663
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Conn Socket Strip RCP 28 POS 2mm Solder ST SMD Milli-Grid? Embossed T/R
PDF
/
Inventory: 1393
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Post 74.8μin 1.90μm
Contact Finish Thickness - Mating 30.0μin 0.76μm
Length 28.19mm
Technical
Max Voltage Rating (AC) 125V
Number of Circuits 26
Contact Resistance 25mOhm
Housing Color Black
Contact Finish - Post Tin
Number of Contacts 28
Row Spacing - Mating 0.079 (2.00mm)
Insulation Color Black
Pitch - Mating 0.079 2.00mm
Current Rating 1A
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.175 4.45mm
Depth 4.19mm
Orientation Vertical
Pitch 2mm
Current Rating (Amps) 1A
Contact Type Female Socket
Contact Finish - Mating Gold
Fastening Type Push-Pull
Voltage - Rated 125V
Number of Rows 2
Applications Automotive, General Purpose, Telecommunications
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 28
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide, Pick and Place
Series Milli-Grid 79109
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Housing Material Polymer
Insulation Material Thermoplastic, Glass Filled
Contact Shape Square
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Contact Material Phosphor Bronze
