M83-LFT1F4N36-0000-000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description
Headers & Wire Housings 3R 36P F VERT PC TAIL 3MM W/JS
PDF
/
Inventory: 3586
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type Through Hole
Contact Shape Circular
Insulation Material Polyphenylene Sulfide (PPS), Glass Filled
Mounting Option 1 LOCKING
Mounting Option 2 JACKSCREW
Technical
Operating Temperature -55°C~125°C
Packaging Tray
Published 2014
Series Datamate J-Tek
JESD-609 Code e4
Feature Mating Guide
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 36
Applications Automotive, General Purpose, Military
Number of Rows 3
Voltage - Rated 120V
Additional Feature COMPATIBLE CONTACT
Fastening Type Screw Lock
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Terminal Pitch 2mm
Insulation Height 0.329 8.36mm
Style Board to Board or Cable
Number of Positions Loaded All
Pitch - Mating 0.079 2.00mm
Insulation Color Black
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 1.457 inch
Row Spacing - Mating 0.079 (2.00mm)
Contact Length - Post 0.118 3.00mm
Number Of PCB Rows 3
PCB Contact Pattern RECTANGULAR
Rated Current (Signal) 3A
Contact Resistance 25mOhm
Insulation Resistance 100000000Ohm
Mating Contact Pitch 0.079 inch
Polarization Key POLARIZED HOUSING
PCB Contact Row Spacing 2.0066 mm
Durability 500 Cycles
Insertion Force-Max 1.0008 N
Withdrawl Force-Min .199882 N
Dimensions
Plating Thickness 12μin
Contact Finish Thickness - Mating 12.0μin 0.30μm
Contact Finish Thickness - Post 10.0μin 0.25μm
Length - Termination 0.118 inch
Stack Height (Mating) 10.65mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
