87551-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 4223
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Lead, Tin
Mount Through Hole
Contact Shape Square
Housing Material Thermoplastic
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination Solder
ECCN Code EAR99
Connector Type Male Pin
Color Black
Number of Rows 1
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating TIN LEAD
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Right Angle
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 0.284 inch
Row Spacing - Mating 2.54 mm
Number Of PCB Rows 1
Number of Contacts 3
Contact Length - Mating 8.0772mm
PCB Contact Pattern RECTANGULAR
Contact Gender Male
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Lead Length 2.79mm
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Body/Shell Style RECEPTACLE
ELV Non-Compliant
Contact Pattern RECTANGULAR
Mating Post Length 8.08mm
High Speed Serial Data Connector No
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
