1364106-4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
LATCHED Rectangular Connector Header
PDF
/
Inventory: 1356
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Length - Termination 0.123 inch
Technical
Mating Contact Row Spacing 0.1 inch
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 2.54 mm
Dielectric Withstanding Voltage 1000VAC V
Polarization Key POLARIZED HOUSING
Termination Type SOLDER
ELV Compliant
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.1 inch
Insulation Resistance 1000000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
Body Depth 0.549 inch
Lead Length 2.79mm
Housing Color Black
UL Flammability Code 94V-0
Operating Temperature (Min) -65°C
Contact Gender MALE
Body Breadth 0.336 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 1.76 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 2.54mm
Total Number of Contacts 20
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
HTS Code 8536.69.40.40
Additional Feature LATCHED
Number of Rows 2
Connector Type Header
ECCN Code EAR99
Physical
PCB Mounting Orientation Vertical
Mounting Option 2 LOCKING
Mounting Style STRAIGHT
Mounting Option 1 LATCH & EJECT
Housing Material Thermoplastic
Contact Shape Square
Number of Pins 20
Mounting Type BOARD
Contact Plating Gold
Contact Material Bronze
