1-146218-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 8394
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Solder, Through Hole
Contact Shape Square
Housing Material Thermoplastic
PCB Mounting Orientation Vertical
Underplate Material Nickel
Technical
Packaging Carton
Termination Solder
ECCN Code EAR99
Connector Type Header, Pin, Plug
Number of Positions 11
Max Operating Temperature 105°C
Min Operating Temperature -65°C
Number of Rows 1
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 9
Approval Agency CSA
Contact Gender MALE
Housing Color Black
Lead Length 2.29mm
Insulation Resistance 5GOhm
ELV Non-Compliant
Mating Post Length 5.842mm
Contact Rating (Current) 3A
High Speed Serial Data Connector No
High Temperature Compatible Yes
Dimensions
Plating Thickness 5μm
Compliance
Flammability Rating UL94 V-0
