185534-3
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Buying Options
Total Price: USD $3.56
Unit Price: USD $3.562546
≥1 USD $3.562546
≥10 USD $3.360899
≥100 USD $3.170653
≥500 USD $2.991181
≥1000 USD $2.821875
Inventory: 2450
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width - Tab 635μm
Tab Thickness 635μm
PCB Thickness 1.6mm
Width 27.8892mm
Length 48.2092mm
Technical
Number of Signal Positions 26
Circuit Application Signal
ELV Compliant
Housing Color Yellow
Number of Contacts 26
Depth 27.9mm
Shielding Unshielded
Orientation Right Angle
Pitch 2.54mm
Gender Male
Number of Rows 2
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 26
Termination Solder
Physical
Housing Material Polybutylene
Contact Plating Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
