TSW-125-07-G-T
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
SAMTEC TSW-125-07-G-T Board-To-Board Connector, Vertical, TSW Series, 75 Contacts, Header, 2.54 mm, Through Hole, 3 Rows
PDF
/
Buying Options
Total Price: USD $5.1
Unit Price: USD $5.0952
≥1 USD $5.0952
≥10 USD $5.0248
≥100 USD $4.8664
≥500 USD $4.576
≥1000 USD $4.0304
≥3000 USD $3.674
Inventory: 116
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 63.5mm
Technical
Max Current Rating 7.6A
Max Voltage Rating (AC) 550V
Housing Color Black
UL Flammability Code 94V-0
Number of Contacts 75
Lead Pitch 2.54mm
Depth 7.62mm
Orientation Straight
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature POLARIZED
Gender Male
Number of Rows 3
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type BOARD CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2005
Physical
Housing Material Polyester
Mounting Type BOARD
Contact Plating Gold
Contact Material Bronze
Supply Chain
Factory Lead Time 2 Weeks
