TMS-109-02-G-S

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description SAMTEC - TMS-109-02-G-S - HEADER, 1.27MM, THT VERT, 9WAY
PDF
/
Inventory: 5351
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Length 11.43mm

Technical

Contact Pattern RECTANGULAR
Max Current Rating 1A
Body/Shell Style RECEPTACLE
Contact Style SQ PIN-SKT
Rated Current (Signal) 5A
Housing Color Black
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number of Contacts 9
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Depth 2.48mm
Orientation Straight
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Gender Male
Number of Rows 1
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type BOARD CONNECTOR
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Published 2012

Physical

Housing Material Polymer
Mounting Type BOARD
Contact Plating Gold
Contact Material Bronze

Supply Chain

Factory Lead Time 3 Weeks
