FTR-106-51-S-D
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Unshrouded Header HDR 12 POS 1.27mm Solder ST SMD Tube
PDF
/
Inventory: 4842
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 30.0μin 0.76μm
Plating Thickness 30μin
Technical
Dielectric Withstanding Voltage 600VAC V
Mating Contact Pitch 0.05 inch
Insulation Resistance 5000000000Ohm
Body Depth 0.1 inch
UL Flammability Code 94V-0
Body Breadth 0.196 inch
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 0.190 4.83mm
Contact Finish - Post Tin
Number Of PCB Rows 2
Shrouding Unshrouded
Row Spacing - Mating 0.100 (2.54mm)
Body Length or Diameter 0.3 inch
Reliability COMMERCIAL
Number of Conductors ONE
Insulation Color Black
Pitch - Mating 0.050 1.27mm
Number of Positions Loaded All
Style Board to Board
Insulation Height 0.100 2.54mm
Total Number of Contacts 12
Current Rating (Amps) 3.1A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
HTS Code 8536.69.40.40
Gender Male
Number of Rows 2
Number of Positions 12
Connector Type Header
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series FTR
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Surface Mount
Contact Material Phosphor Bronze
