90121-0128
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 8POS .100 R/A TIN
PDF
/
Buying Options
Total Price: USD $1.02
Unit Price: USD $1.015612
≥1 USD $1.015612
≥10 USD $0.958117
≥100 USD $0.903891
≥500 USD $0.852729
≥1000 USD $0.804457
Inventory: 987
Minimum: 1
-
+
Technical Details
Technical
Insulation Resistance 5000000000Ohm
Body/Shell Style RECEPTACLE
Dielectric Withstanding Voltage 350VDC V
Contact Pattern RECTANGULAR
Insertion Force-Max 3.0024 N
Glow Wire Compliant Non-compliant
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
UL Flammability Code 94V-0
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.7564mm
Lead Pitch 2.54mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 3A
Orientation Right Angle
Total Number of Contacts 8
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature C-GRID III
Voltage - Rated 350V
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 8
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Housing Material Polyester
Mount Through Hole
Contact Plating Tin
Contact Material Brass
