70553-0055

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Headers & Wire Housings CGrid SL Srd Hdr 120 Hdr 120 RA Tin 21Ckt
PDF
/
Inventory: 2252
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Bronze
Contact Plating Tin
Mount Through Hole
Material Brass
Housing Material Thermoplastic

Technical

JESD-609 Code e3
Pbfree Code yes
Termination Solder
ECCN Code EAR99
Connector Type Male Pin
Number of Positions 21
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Black
Number of Rows 1
Gender Male
Voltage - Rated 250V
Additional Feature LATCHED
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 21
Orientation Right Angle
Reach Compliance Code unknown
Current Rating 3A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 1
Contact Length - Mating 6.096mm
PCB Contact Pattern RECTANGULAR
Body Breadth 0.275 inch
UL Flammability Code 94V-0
Body Depth 0.535 inch
Contact Style SQ PIN-SKT
Body/Shell Style RECEPTACLE
ELV Compliant
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant

Dimensions

Height 5.08mm
Length 55.9mm
Width 13.6mm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
