53253-1010
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 10POS 2MM VERT TIN
PDF
/
Inventory: 9479
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Glow Wire Compliant Non-compliant
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 500VAC V
Polarization Key HOUSING SIDE
Body/Shell Style RECEPTACLE
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 0.5A
UL Flammability Code 94V-0
Operating Temperature (Min) -20°C
Contact Gender Male
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 85°C
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 3.302mm
Number Of PCB Rows 1
Body Length or Diameter 0.866 inch
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 2A
Orientation Vertical
Total Number of Contacts 10
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature DOVETAILED MATING GUIDES
Voltage - Rated 125V
Number of Rows 1
Color Natural
Number of Positions 10
Connector Type Male Pin
Termination Kinked Pin
Physical
Housing Material Nylon
Mount Through Hole
Contact Plating Lead, Tin
Contact Material Brass
