43650-0604

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description Header Connector, pcb Mount, recept, 6 Contacts, pin, 0.118 Pitch, pc Tail Terminal
PDF
/
Buying Options
Total Price: USD $2.13
Unit Price: USD $2.132886
≥1 USD $2.132886
≥10 USD $2.012158
≥100 USD $1.898262
≥500 USD $1.790813
≥1000 USD $1.689452
Inventory: 1109
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant

Dimensions

Width 9.9mm
Length 21.6mm
Height 4.37mm

Technical

Glow Wire Compliant Compliant
Halogen Free Low Halogen
Durability 30 Cycles
Body/Shell Style RECEPTACLE
Contact Style SQ PIN-SKT
Body Depth 0.39 inch
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender Male
Number of Contacts 6
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 5A
Orientation Right Angle
Pitch 3mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating AU ON NI
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Additional Feature POLARIZED
Voltage - Rated 600V
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Pbfree Code yes

Physical

Housing Material Plastic
Shell Material LIQUID CRYSTAL POLYMER
Mount Through Hole
Contact Plating Gold
Contact Material Brass
