22-43-6120
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Headers & Wire Housings 2.5 Spox Hdr WB Shrd ShrdStgF White 12ckt
PDF
/
Inventory: 4739
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Housing Material Polyester
Technical
Packaging Bulk
Published 2013
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Press-Fit
ECCN Code EAR99
Connector Type Male Pin
Number of Positions 12
Color White
Number of Rows 1
Gender Male
Voltage - Rated 250V
Additional Feature STAGGRED PIN
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.4892mm
Total Number of Contacts 12
Orientation Vertical
Current Rating 3A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Number Of PCB Rows 2
Contact Length - Mating 3.5052mm
PCB Contact Pattern STAGGERED
Operating Temperature (Max) 75°C
UL Flammability Code 94V-0
Body Depth 0.283 inch
Rated Current (Signal) 3A
Contact Style RND PIN-SKT
Contact Resistance 20mOhm
Body/Shell Style RECEPTACLE
Polarization Key ENDS
Durability 25 Cycles
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant
Dimensions
Height 7.19mm
Length 32.4mm
Width 4.17mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
