1720640012

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description CONN HEADER R/A 12POS 5.7MM
PDF
/
Buying Options
Total Price: USD $7.08
Unit Price: USD $7.0752
≥1 USD $7.0752
≥10 USD $6.27088
≥100 USD $5.661814
Inventory: 828
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Post 100.0μin 2.54μm
Contact Finish Thickness - Mating 15.0μin 0.38μm

Technical

Contact Finish - Post Tin
Shrouding Shrouded - 4 Wall
Contact Length - Post 0.142 3.60mm
Row Spacing - Mating 0.224 (5.70mm)
Insulation Color Black
Pitch - Mating 0.224 5.70mm
Number of Positions Loaded All
Style Board to Cable/Wire
Insulation Height 0.572 14.53mm
Contact Type Male Pin
Contact Finish - Mating Gold
Fastening Type Locking Ramp
HTS Code 8536.69.40.30
Number of Rows 2
Applications Automotive, General Purpose, Industrial, Telecommunications
Number of Positions 12
Connector Type Header
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide, Glow Wire Compliant
Series Mega-Fit
Published 2013
Packaging Tray

Physical

Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Mounting Type Through Hole, Right Angle
Contact Material Copper

Supply Chain

Factory Lead Time 8 Weeks
