15-91-3094
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 9POS .100 R/A SMD
PDF
/
Buying Options
Total Price: USD $3.82
Unit Price: USD $3.818311
≥1 USD $3.818311
≥10 USD $3.602186
≥100 USD $3.398283
≥500 USD $3.205928
≥1000 USD $3.024469
Inventory: 5397
Minimum: 1
-
+
Technical Details
Technical
Glow Wire Compliant Non-compliant
Mating Post Length 6.1mm
Contact Pattern RECTANGULAR
Durability 50 Cycles
Polarization Key POLARIZED HOUSING
ELV Compliant
Body/Shell Style RECEPTACLE
Contact Resistance 30mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.66 inch
Contact Gender Male
Body Breadth 0.275 inch
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 6.096mm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL, CSA
Number of Conductors ONE
Current Rating 3A
Orientation Right Angle
Total Number of Contacts 9
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature SL, LOW PROFILE
Voltage - Rated 250V
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 9
Connector Type Male Pin
Termination Solder
Part Status Active
Pbfree Code yes
Published 2012
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Physical
Housing Material Polyester
Material Brass
Mount Surface Mount
Contact Plating Tin
Contact Material Bronze
Supply Chain
Factory Lead Time 9 Weeks
