15-47-7620
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
CONN HEADER 20POS .100 VERT GOLD
PDF
/
Buying Options
Total Price: USD $4.14
Unit Price: USD $4.135381
≥1 USD $4.135381
≥10 USD $3.901302
≥100 USD $3.680476
≥500 USD $3.472142
≥1000 USD $3.275613
Inventory: 1127
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length - Termination 0.13 inch
Plating Thickness 15μin
Width 10.7mm
Technical
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Contact Pattern RECTANGULAR
Durability 50 Cycles
Dielectric Withstanding Voltage 600VDC V
Polarization Key CTR W/GUIDE SLOTS
ELV Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 1000000000Ohm
Contact Resistance 15mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.475 inch
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Contact Length - Mating 8.001mm
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 2.5A
Orientation Vertical
Total Number of Contacts 20
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Fastening Type Latch
HTS Code 8536.69.40.40
Voltage - Rated 250V
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 20
Connector Type Male Pin
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Published 2008
Physical
Housing Material Thermoplastic
Material Brass
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
Supply Chain
Factory Lead Time 10 Weeks
