22-43-3110
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
RECEPTACLE, 11WAY
PDF
/
Inventory: 5551
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Bronze
Contact Plating Tin
Mount Free Hanging
Housing Material Polyester
Technical
Published 2008
Pbfree Code yes
Part Status Active
Termination IDC
ECCN Code EAR99
Connector Type IDC, Receptacle, Socket
Number of Positions 11
Color Natural
Number of Rows 1
Gender Receptacle
Voltage - Rated 250V
Additional Feature SPOX
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.4892mm
Total Number of Contacts 11
Current Rating 3A
Reference Standard UL, CSA
Reliability COMMERCIAL
Contact Gender Female
Operating Temperature (Min) -40°C
UL Flammability Code 94V-0
Rated Current (Signal) 3A
Contact Style RND PIN-SKT
Contact Resistance 20mOhm
Body/Shell Style PLUG
Polarization Key POLARIZED HOUSING
Wire/Cable Type Discrete
Wire Gauge (Max) 24 AWG
Wire Gauge (Min) 26 AWG
Durability 25 Cycles
Contact Pattern RECTANGULAR
Glow Wire Compliant Non-compliant
Dimensions
Length 29.9mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
