0435880010
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Power HDR 4 POS 4.2mm Solder ST Thru-Hole 4 Terminal 1 Port Bulk
PDF
/
Inventory: 5316
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Technical
Packaging Bulk
Series Mini-Fit Jr 43588
Feature Board Lock
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Termination Solder
Connector Type Header
Number of Positions 4
Applications General Purpose, Industrial, Telecommunications
Number of Rows 2
Fastening Type Locking Ramp
Contact Finish - Mating Tin
Contact Type Male Pin
Pitch 4.2mm
Orientation Straight
Insulation Height 0.504 12.80mm
Style Board to Cable/Wire
Number of Positions Loaded All
Pitch - Mating 0.165 4.20mm
Row Spacing - Mating 0.165 (4.20mm)
Contact Length - Post 0.138 3.50mm
Shrouding Shrouded - 4 Wall
Number of Contacts 4
Contact Finish - Post Tin
Number of Ports 1
Dimensions
Contact Finish Thickness - Mating 35.4μin 0.90μm
Contact Finish Thickness - Post 35.0μin 0.90μm
Compliance
Material Flammability Rating UL94 V-2
RoHS Status ROHS3 Compliant
