09185246923
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Male Pin Rectangular Connector
PDF
/
Inventory: 1811
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.114 inch
Technical
Insulator Color GRAY
Mating Contact Row Spacing 0.1 inch
Contact Pattern RECTANGULAR
Polarization Key POLARIZED HOUSING
Insulation Resistance 1000000000Ohm
Contact Style SQ PIN-SKT
Rated Current (Signal) 2A
Body Depth 0.681 inch
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.335 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 24
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 2A
Orientation Right Angle
Pitch 2.54mm
Subcategory Headers and Edge Type Connectors
Number of Rows 2
Connector Type BOARD EURO CONNECTOR
Termination Solder
Part Status Active
JESD-609 Code e3
Physical
Mounting Option 1 LOCKING
Mounting Type BOARD
Contact Material COPPER ALLOY
