08-70-1039
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
MOLEX 08-70-1039Contact, SPOX BMI, 5263 Series, Socket, 28 AWG, 22 AWG, Crimp, Brass
PDF
/
Buying Options
Total Price: USD $0.07
Unit Price: USD $0.071688
≥1 USD $0.071688
≥500 USD $0.052715
≥1000 USD $0.043929
≥2000 USD $0.040302
≥5000 USD $0.037669
≥10000 USD $0.035035
≥15000 USD $0.033888
≥50000 USD $0.033323
Inventory: 988
Minimum: 1
-
+
Technical Details
Technical
Min Operating Temperature -40°C
Gender Receptacle
Additional Feature CONTACT FINISH: TIN
HTS Code 8536.90.40.00
Max Operating Temperature 105°C
Connector Type Connector, PCB, Signal
ECCN Code EAR99
Termination Crimp
Pbfree Code yes
Published 2001
Packaging Cut Tape
Used With 5264
Cable Entry-Min 0.0452 inch
Cable Entry-Max 0.0748 inch
Assembly Item Name CONTACT
Current Rating (Max) 3A
Wire/Cable Gauge 28 AWG
Wire Gauge (Min) 28 AWG
Wire Gauge (Max) 22 AWG
Connector Support Type CONNECTOR ACCESSORY
Contact Resistance 20mOhm
Contact Style BELLOWED CONTACT
Contact Gender Female
Number of Contacts 1
Current Rating 3A
Depth 2.4mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 250V
Physical
Weight 43.204673mg
Mount Cable
Contact Plating Tin, Gold
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Length 7mm
Height 2.2mm
