09185207913800
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
SEK ROHS3Compliant Keying Slot Mounting Flange Square Connector Header -55C~125C 0.228 5.80mm
PDF
/
Inventory: 8112
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole, Right Angle
Contact Shape Square
Insulation Material Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series SEK
Feature Keying Slot, Mounting Flange
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Header
Number of Positions 20
Color Grey
Number of Rows 2
Fastening Type Latch Lock/Eject Hooks, Short
Contact Type Male Pin
Insulation Height 0.335 8.51mm
Style Board to Cable/Wire
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Gray
Row Spacing - Mating 0.100 (2.54mm)
Shrouding Shrouded - 4 Wall
Contact Length - Mating 0.228 5.80mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
